Deskripsi
Features Alinco DJ-MX1
- Ready to sail, antenna, Li-Ion battery pack and rapid charger are all standard
- Operates up to 8 hours without recharging
- International, US and Canadian channels preprogrammed
- Submersible 1m for 30 minutes (IPX7)
- Floats in water even with supplied accessories and lets you know where it is with a flashing red LED light
- 5 Watts output, 1W switchable
- Highly legible display with automatic back light
- Weather channel alert, Channel & Priority Scanning, Dual / Tri -Watch, Call channel and more!
Specifications Alinco DJ-MX1
GENERAL |
|
| Frequency range | Tx : 156.025-157.425MHz |
| Rx : 156.050-163.275MHz | |
| Frequency stability | ±10ppm |
| Emission type | FM (16K0G3E) |
| Antenna impedance | 50 Ω |
| Rated voltage | 7.2V (Battery) |
| Current Consumption | 0.35A (Max audio output) |
| 1.5A (TX / 5W) / 0.9A (TX / 1W) | |
| (Battery life up to 8 hours with TX5 / RX5 / Stand-by 90 cycles) | |
| Operating temperature | －20～ +60℃ |
| Ingress protection | IPX7 |
| Dimensions (WxHxD) | 63mm x 138mm x 43mm approx. |
| Weight (approx.) | 288g with battery, antenna and clip |
TRANSMITTER |
|
| RF Output Power | 5 W / 1 W |
| Modulation Type | Variable Reactance |
| Spurious Emission | ≥68dB |
| Frequency deviation | ± 5KHz |
RECEIVER |
|
| Circuit | Double-Conversion Superheterodyne |
| Intermediate Frequencies | 1st: 21.7 MHz |
| 2nd: 450 kHz | |
| Sensitivity | 0.22µV (12 dB SINAD) |
| Adjacent Channel Selectivity | 70 dB |
| Intermodulation response | 68 dB |
| Audio Output | 0.5W ( 8Ω10 %THD) |
Standard Accessories (available also as spares)
- EBP-104 Li-Ion battery pack (7.4V / 1200mAh)
- EDC-298 220 V AC adapter
- ECD-294 Rapid stand charger
- EA-257 Whip antenna
- EBC-54 Belt Clip
Optional Accessories
- EME-32A* Earphone Microphone
- EME-36A* Earphone Microphone
* The microphone/PTT units of EME-32A/36A are not watertight. Avoid using them in wet conditions.
- EMS-71 IP67 Speaker Microphone
