The Yokogawa AQ1210 series OTDR is designed to empower field technicians to make fast and precise measurements with confidence. The AQ1210 OTDR delivers high reliability with its robust design for operating under harsh field conditions. Engineered with innovative technology, the AQ1210 features dual operation mode by multi-touch touchscreen and hard-key buttons as well as fully automatic measurement and easy-to-read analysis reports through new software applications. In addition, the AQ1210 enhances productivity and operability with its lightning startup time, multi-tasking operation, and immediate reporting via wireless connectivity.
7 types of Model lineup
Seven models ideal for installation and maintenance of various optical communication access networks
Compact body with long hour operation
Footprint approx. size of A5 paper, weight of 1 kg (2.2 Lbs.)
10 hours battery operation
Intuitive operation by touch and hard keys
The AQ1210 features a capacitive multi-touch touchscreen, 5.7-inch LCD, and a “field use” friendly rotary dial.
Data transfer and remote control via Wi-Fi or ETHERNET connection.
Enhanced OTDR performance
Measurement of PON systems with up to 128 splits
Hi-Speed real-time measurement
Functions and features for improved work efficiency
Multi-fiber measurement, Smart mapper function, PDF reporting
Much more than an OTDR
A variety of optional features for multi-tasking.
|Cut Filter||Number of
|Dynamic range (dB)(Typ)||Application|
|Port1 (nm)||Port2 (nm)||Installation||Maintenance|
Excellent hardware performance and advanced analysis algorithm enable the AQ1210 to accurately characterize Passive Optical Networks (PON) through high-port-count splitters (up to 1 × 128)*.
The AQ1210 assists beginner/expert users in simply configuring OTDR measurement settings based on PON topology information for optimal results. Short event dead zone and high sampling resolution enable users to detect as close as 0.5 meters (<20 inches)*.
*Typical, with AQ1215A/E/F and AQ1216F
